Model
ALKO CONV220-12-20A
Input voltage range AC
165-265 VAC
Input voltage range DC
190-280VDC
Output voltage range
10~20VDC
Output rated value
12VDC
Output Current
5A~10A~20A~30A~40A~50A~60A~70A~80A~90A~100A....
Load regulation
≤0.5%
Power grid regulation
≤0.1%
Degree of imbalance for equalized current
≤±3%
Phone weighted noise voltage
≤2mV(CCITT)
Peak—peak noise
≤200mV
Wide frequency noise
≤50mV
Discrete noise
≤20mV
Efficiency
>92%
Dynamic response
20% ~ 100% step load≤200Restoring time≤100uS
Working temperature
-5~450C
Cooling mode
Temperature control wind cooling
MTBF
100,000Hour
insulation strength
<30mA
Dimension
1U/ 2U
