THÔNG SỐ KỸ THUẬT
Inverter 48VDC/220VAC/1000VA
Điệp áp vào: 220VAC
Dải điện áp vào AC: 165-265 VAC
Điện áp vào : 48VDC
Dải điện áp vào AC: 40-60VDC
Điện áp ra AC: 220VAC
Công suất: 1000VA
|
MODEL |
ALKO TS1000 |
|
Nominal Power |
1000VA |
|
AC INPUT BYPASS |
|
Phase & Waveform |
Single phase & Sinewave |
|
Voltage |
220VAC |
|
Acceptable Voltage |
165-265VAC (Wide mode) |
|
Frequency |
50Hz or 60Hz (Auto sensing) |
|
OUTPUT |
|
Phase & Waveform |
Single phase & sinewave (Bypass mode sync to input) |
|
Voltage |
220VAC (Bypass mode sync to input) |
|
Voltage Regulation |
±10%rms (Bypass mode sync to input) |
|
Frequency |
50Hz±0.3Hz (bypass mode sync to input) |
|
Power Factor |
0.9-1.0 |
|
DC INPUT |
|
Battery Voltage |
48VDC |
|
Ranger Voltage |
40-60VDC |
|
Low Battery Alarm |
40VDC |
|
Low Battery Transfer |
40VDC |
|
High Voltage Alarm |
60VDC |
|
Over Charge Voltage |
No |
|
TRANSFER EFFICIENCY |
|
Line Mode |
>95% |
|
Battery Mode |
>75% |
|
Power saver |
Available when the load is less than 10-25 Watts |
|
INDICATORS |
|
Lcd Display |
Lcd Ac-in, Lcd Inverter, Lcd Fault |
|
Audible Alarm |
Overload |
|
Protections |
Low battery, over temp, over load |
|
ENVIROMENTAL |
|
Operating Environment |
0-40C,0-90%RH (Non-condensing) |
|
Audible Noise |
<60dB |
|
Dimension (H*W*D)(mm) |
Rack 19 inch 2U (88*440*320) |
|
Weight (Kg) |
10 |
