| ODEL |
Alko_9017 |
| Nominal Power | 1000VA |
| AC INPUT BYPASS |
| Phase & Waveform | Single phase & Sinewave |
| Voltage | 220VAC |
| Acceptable Voltage | 165-265VAC (Wide mode) |
| Frequency | 50Hz or 60Hz (Auto sensing) |
| OUTPUT |
| Phase & Waveform | Single phase & sinewave (Bypass mode sync to input) |
| Voltage | 220VAC (Bypass mode sync to input) |
| Voltage Regulation | ±10%rms (Bypass mode sync to input) |
| Frequency | 50Hz±0.3Hz (bypass mode sync to input) |
| Power Factor | 0.9-1.0 |
| DC INPUT |
| Battery Voltage | 48VDC |
| Ranger Voltage | 40-60VDC |
| Low Battery Alarm | 40VDC |
| Low Battery Transfer | 40VDC |
| High Voltage Alarm | 60VDC |
| Over Charge Voltage | No |
| TRANSFER EFFICIENCY |
| Line Mode | >95% |
| Battery Mode | >75% |
| Power saver | Available when the load is less than 10-25 Watts |
| INDICATORS |
| Lcd Display | Lcd Ac-in, Lcd Inverter, Lcd Fault |
| Audible Alarm | Overload |
| Protections | Low battery, over temp, over load |
| ENVIROMENTAL |
| Operating Environment | 0-40C,0-90%RH (Non-condensing) |
| Audible Noise | <60dB |
| Dimension (H*W*D)(mm) | Rack 19 inch 2U (88*440*320) |
| Weight (Kg) | 10 |
